MF spiral
Alfa Laval'ın mikrofiltrasyon spiral membranları, optimum temizlik koşulları sağlayan sıhhi bir tasarımda benzersiz bir polipropilen destek malzemesi yapısına dayanmaktadır. Spiral membranlar, farklı mikrofiltrasyon membran tipleri ve farklı kombinasyonlarda mevcuttur.
Alfa Laval microfiltration (MF) spiral membranes are extremely cost-effective to operate, largely as the result of the low energy consumption involved. They also have the advantage of eliminating the frequent replacement and disposal of the cartridges and other consumables used in traditional dead-end filtration.
Alfa Laval microfiltration spiral membranes are extremely durable, with service lives that can extend over more than five years.
Microfiltration is used on feed streams where the aim is to remove small-diameter dispersed solids such as bacteria, fat and oil globules without affecting the balance of the components dissolved within the stream.
Alfa Laval offers two series of microfiltration spiral membranes with different pore sizes and flux properties. The membrane materials are either polysulphone polymer or fluoro polymer based on polypropylene support material.
MFG series
The MFG microfiltration spiral membrane is made of polysulphone polymer. The spiral membrane is avaiable in the types MFG1 and MFG2 with pore sizes of 0.1 µm and 0.2 µm respectively.
MFP series
The MFP microfiltration spiral membrane is made of fluoro polymer. This spiral membrane is available in type MFP2 having a pore size of 0.2 µm and MFP5 and MFP8 with pore sizes of 0.5 µm and 0.8 µm respectively.
Benefits
- cost-effective operation due to low energy consumption
- long life time compared to traditional dead-end filtration
- cover a broad spectrum of flux properties and pore sizes
- available in different combinations of length, diameter and spacer size
- sanitary design with all materials in compliance with EU Regulation (EC) 1935/2004, EU Regulation 10/2011 and FDA regulations (CFR) Title 21
- same membrane types available as both flat sheet membranes and spiral membranes
- suitable for extensive range of processes
- manufactured by Alfa Laval's own membrane centre
Nasıl çalışır
Membran filtrelemenin arkasındaki temel prensip, bir sıvıyı iki farklı akışkana ayırmak için yarı geçirgen bir membranın kullanılmasıdır.
Sıvının membran yüzeyi boyunca çapraz akışta pompalanmasıyla membranın gözeneklerinden daha küçük bileşenlerin geçmesine izin verilir. Oluşturulan pozitif bir basınç sayesinde istenen permeat formu yakalanır.
Gözenek boyutundan daha büyük herhangi bir bileşen geçemez ve çökelti kısımda geride kalır. Spiral sarımlı membranın yüzeyi, membran yüzeyine paralel hareket eden sıvı akışının kuvveti sayesinde tıkanıklıklardan korunur.
Etkin spiral membran filtrelemesi
Bir spiral membran, her biri merkezi bir permeat toplama tüpüne yapıştırılmış, bir permeat ara ağı ile ayrılmış iki membran tabakasına sahip birkaç membran 'zarfından' oluşur.
Her bir membran sarmalı arasında besleme kanalını oluşturan bir ara parça bulunur. Böylece beslenen ürünün membran boyunca akmasına izin verilir. Membrandan geçen ürün; permeat toplama tüpüne akar
Kırmızı = Besle/tut.
Yeşil = Geçir.
